All Mechanica workshops can be administered on both Weekends and Weekdays


Pro/MECHANICA- Week Long

Overview: This course is designed for new users who want to test, validate, and optimize pro engineer models. Mechanica enables you to simulate structural and thermal loads on products. You will also complete comprehensive, hands-on lab exercises that simulate realistic analysis and design optimization activities. Advanced topics such as combined mechanical and thermal analysis techniques are also covered. The course will cover all the modules of Pro/MECHANICA in detail with an emphasis on your specific interests as the instructor likes to help each individual separately. Participants will learn to calculate stresses, vibrations, and deformation of parts, as well as temperatures and heat flow, and to perform optimization studies. The end result will be reduced design time by providing concurrent simulation during the design process. Like most of our workshops, Class size is small to maximize access to the instructor.

Discussion:
Discuss the difference between Ansys Cosmos and Mechanica
Learn about the new functions of the most recent version of Mechanica
Learn to solve nonlinear large displacement, pre-stress, dynamic, and transient thermal analyses
Discuss strengths and weaknesses of Mechanica
Discuss reduced design time by providing concurrent simulation during the design process
Discuss how to set up a model for solving beams
Discuss solving for sheet metal products such as battery contacts or brackets.
Learn to simulate advanced materials behaviors such as hyper-elasticity, anisotropic, orthotropic, and composite laminates
Learn support for advanced modeling entities such as mass/spring idealizations, pre-loaded bolts, and friction on assembly contact points
Go over common interface, workflows, and user concepts as in core design areas of Pro/ENGINEER
Learn to reduce product performance uncertainty by simulating complex systems accurately
Discuss solving for assemblies
Discuss solving for weldments
Discuss Louvers for sheet metal
Discuss the fringe plot of Von Mises stress analysis and the FEA solutions for optimizing a solution for strength cost and robust

Both courses are offered on the weekends or weekdays. We develop all of our own training material in HTML for students to access during and after the classes. These tutorials can be customized for specific industries and licensed and utilized within a corporate intranet. Call to inquire if you don't see this course offered on our schedule. We also offer custom Pro/MECHANICA workshops to fit your specific needs. Contact your DESIGN ENGINE|EDUCATION representative for specific in formation.
